BIU-014
BIU-014
or
Call 1-866-609-2672
Description
Working height H = 120mm
Tip angle α = 60°
Radius R = 3mm
CNC-Deephardened® (≥ 4mm / 56-60HRC)
Max. load = 160ton/m
New Standard Premium top tool with Working height H=120mm, α=60°, Radius=3mm, precision ground and CNC-Deephardened® (at least 4mm / 56-60HRc), Material=CR-MO, Max. load=160ton/m. Provided with Safety-Clicks™, which allows you to change the tooling vertically.
Specifications
| Condition | New |
| Type/length | BIU-014/1 515mm, BIU-014/2 550mm (segmented), BIU-014/3 200mm (segmented), BIU-014/11 200mm (segmented), BIU-014/12 255mm, BIU-014 1x:20mm, BIU-014 1x:25mm |
| Safety | Safety-Clicks® |
| Weight | 12.3kg, 13.1kg, 4.8kg, 6.1kg, 0.5kg, 0.6kg |
