SU-280 G

SU-280 G
or
Call 1-866-609-2672
Description
This Utility band saw makes cutting metal effortless. The SU-280 G combines the cutting of a traditional band saw with the flexibility and accuracy of a cold saw. For larger material that requires a bandsaw, this scaled-down but rugged horizontal band saw can easily cut through round material up to 8-inch diameter and features a swing head that can miter 60 degrees right of 90, giving you a 30-degree cut part without material movement.
The SU280 G bandsaw also features a metered feed rate allowing for quick and effortless cuts without operator assistance! It's the perfect saw for any fabricating shop and is built with the durability and quality you expect from a Scotchman; plus it's backed by our outstanding 3-year warranty.
Quick action locking vise
Miter capability 60° right of 90°∟
Blade trigger switch
Blade tension gauge
Gravity feed with adjustable down-feed pressure
Carbide blade guides with roller supports
Re-circulating coolant system
Band door interlocks
One band saw blade
One gallon coolant
Meets CE standards
Made in Spain
Specifications
Model | SU-280 G |
Condition | New |
TUBINGRoundSquareRectangle | 90 Degree8"8"11" x 7-3/4", 45 Degree7"6-1/4"7" x 6-1/4", 60 Degree4-1/4"4"4-1/4" x 4" |
Blade Length | 1" x 96.5", , |
Two Cutting Speeds (3-phase machines) | 131/262 FPM, , |
One Cutting Speed (1-phase machines) | 196 FPM, , |
Motor Rate | 1.3 hp, 1 kW, |
Motor Options(Factory Wired) | Must Specify:230/460v, 3 ph220v, 1 ph, , |
Width | 33-1/2", 85 cm, |
Depth | 55", 140 cm, |
Height | 69", 175 cm, |
Shipping Weight (may vary) | 650 lbs, 295 kg, |
Warranty | Three years on parts |
