CPO 350 NF PK

CPO 350 NF PK

Description

If you are looking for a precision nonferrous metal cutting saw, this powerful American-made Circular Cold Saw takes sawing to the next level. The CPO350 NF PK coldsaw is designed to make extremely fast and accurate cuts through non-ferrous metals like aluminum, plastic, and copper. This wet saw features a mist coolant lubrication system, a double clamping self-centering air-operated vise and operator controlled trigger switch to ensure safe, precise, fast, burr-free, high quality, volume parts. The CPO 350 NFPK saw has 180 degrees of mitering capabilities and a built-in miter-locking device that makes quick, accurate stops at 45 degrees left, 90 degrees straight, and 45 degrees right, and has the ability to slot and notch. Accuracy within 1° of mitering and a squareness tolerance of ±0.002 per diameter inch in height; the real payoff for this machine is fast, clean and extremely accurate cuts. Additional machine features include a chip drawer, a 3,000 rpm motor and utilizes up to a 14" diameter (350mm) carbide tipped sawblade giving it the ability to cut 4-1/2" OD max round tube at 90° and 3" max round or square solid at 90 degrees. The CPO 350NF PK saw is a dependable machine built for industrial use, and with the quality you expect from a Scotchman. Always backed by our 3-Year Warranty and lifetime customer support! Pair this machine with a Scotchman digital measuring system to automate the measuring process; simply enter the desired length on the touchscreen and the stop will automatically move to the correct length. Air operated double self-centering vise assures burr-free cuts Operator controlled trigger switch Miter capabilities 45 degrees left to 45 degrees right Miter locking device: Quick, accurate settings-stops at 45 degrees left, 90 degrees, and 45 degrees right Capable of slotting Positive-driven cogged belt system Chip drawer Mist coolant lubrication system One 350 mm diameter carbide-tipped blade One blade wrench One gallon coolant Complies with ANSI B11.10 safety standards Made in USA

Specifications

ModelCPO 350 NF PK
ConditionNew
Cutting Speed3,000 rpm, Motor Rate:5 hp,
Maximum Cutting Capacities(Non-Ferrous & PVC )TUBINGRoundSquareRectangle, 90 Degree4-1/2" 4-1/4" x 4-1/4" 5-1/2" x 4", 45 Degree4-1/4" 4" x 4" 4" x 4"
SOLIDRoundSquare90 Degree3" 3" x 3", 45 Degree2-1/2" 2-1/2" x 2-1/2"
Motor Options (Factory Wired)Specify:208/230/460v, 3 ph, ,
Maximum Diameter Blade350 mm, ,
Arbor Bore40 mm, ,
Pin Spacing4/12/64, ,
Width21-7/8", 55.5 cm,
Depth43-1/2", 110.5 cm,
Height (not including feed handle)56-1/4", 143 cm,
Height (floor to vise)37-7/16", 95 cm,
Shipping Weight (may vary)655 lbs., 297 kg,
WarrantyThree years on parts
